SHT40 Temperature & Humidity Sensor Breakout I2C Qwiic

(No reviews yet) Write a Review
$4.74
Sku:
ES-13514
Availability:
Ships within 24 Hours
Adding to cart… The item has been added

The SHT40 Breakout with Qwiic Connector is a high-precision temperature and humidity sensor module engineered for developers and engineers who require accurate environmental data in a compact and reliable form factor. Developed using Sensirion’s CMOSens Technology, this module integrates a high-performance sensing element and signal processing circuit on a single chip, delivering unmatched accuracy with ultra-low power consumption - just 1.2 µW in ultra-low power mode. Its robust design and exceptional performance make it ideal for environmental monitoring, smart agriculture, HVAC systems, and IoT-based weather stations.

With a temperature measurement range of -40°C to +125°C and an impressive accuracy of ±0.2°C, as well as a humidity detection range of 0% to 100% RH with ±1.5% RH accuracy, this module is a reliable solution for any temperature or humidity-sensitive application. The integrated Qwiic connector enables effortless daisy-chaining with other I²C-compatible devices—no soldering, no fuss, just plug-and-play functionality. Full support is available for major microcontroller platforms, including Arduino, Raspberry Pi, and ESP32, with well-documented libraries and examples that ensure a smooth setup process.

Key Features

  • High Accuracy Measurements
    ±0.2°C temperature accuracy and ±1.5% RH humidity accuracy ensure reliable environmental data.

  • Ultra-Low Power Consumption
    Consumes only 1.2 µW in low-power mode, making it ideal for battery-powered and IoT devices.

  • Wide Operating Range
    Measures from -40°C to 125°C and 0% to 100% relative humidity, suitable for extreme conditions.

  • Qwiic Connector Enabled
    Simplifies setup with plug-and-play compatibility—no soldering required for I²C connections.

  • CMOSens Technology
    Integrates sensor element and signal processing on a single chip for maximum precision and stability.

  • Broad Microcontroller Compatibility
    Supports Arduino, Raspberry Pi, and other popular development boards with ready-to-use libraries.

  • Compact and Durable Design
    Compact PCB size fits easily into any enclosure or embedded system while maintaining mechanical stability.

Resources

SHT40 Board Dimensions

Operating Voltage:
3.3V-5V
Operating Current:
0.45mA
Interface:
I2C
Response Time:
8s (tau63%)
Humidity Measurement Range:
0~100%RH
Humidity Measurement Accuracy:
+-1.8%
Temperature Measurement Range:
-40~125C
Temperature Measurement Accuracy:
+-0.2C
Size:
30x22mm
