The LM335 Precision Temperature Sensor is a low-cost analog sensor designed for temperature measurement from −40°C to +100°C. It operates like a two-terminal Zener diode and produces an output voltage directly proportional to absolute temperature at 10 mV/K. The sensor requires a suitable bias resistor and can be connected to an ADC, voltmeter, or analog control circuit. An adjustment terminal is also provided for optional single-point calibration to improve accuracy.
Key Features
- Provides a linear analog output of 10mV per Kelvin.
- Supports a temperature measurement range of −40°C to +100°C.
- Operates with a bias current from 400µA to 5mA.
- Features low dynamic impedance of less than 1Ω.
- Supports optional calibration using the adjustment terminal.
- Suitable for temperature monitoring, data logging, thermal protection, and control systems.
Resources
- Category:
- Temperature sensor probe
- Communication interface:
- Analog Communication
- Operational voltage:
- 5V to 30V DC
- Measures:
- Temperature
- Operational Temperature:
- -40C to 100C
- Temperature accuracy:
- 1C
- Cable length:
- 1Meter
