The 7Semi UCC27516 Gate Driver Breakout Board integrates Texas Instruments' UCC27516DRSR, delivering 4A peak-source and 4A peak-sink currents for efficient MOSFET and IGBT switching. It features a wide operating voltage range of 4.5V to 18V, minimal propagation delay of 13ns, and robust noise immunity, making it ideal for high-performance power electronics applications.
Key Features:
-
Optimised Power Delivery: Achieves symmetrical 4-A Peak-Source and 4-A Peak-Sink drive current, providing efficient and reliable power switching.
-
Ultra-Fast Switching: Experience minimal propagation delay with typical values as low as 13 ns, ensuring rapid and accurate switching operations.
-
Versatile Voltage Range: Operates efficiently within a wide VDD range of 4.5 to 18 V, accommodating various power levels and application needs.
-
Temperature Resilient: Designed to function across a broad temperature range of -40°C to 140°C, making it suitable for extreme environments.
-
Enhanced Noise Immunity: Features hysteretic-logic thresholds for high-noise immunity, ensuring stable performance in electrically noisy environments.
-
Glitch-Free Operation: Internal undervoltage lockout (UVLO) circuitry guarantees glitch-free operation during power up and power down.
