7Semi BME690 Digital Sensor Nano Breakout Qwiic – Temperature, Humidity, Pressure, Gas | I2C

SKU
ES-12255

Combines temperature, humidity, barometric pressure and gas sensing for environmental monitoring.

BME690 Digital Sensor Nano Breakout Qwiic – Temperature, Humidity, Pressure, Gas

Select a photo to enlarge it.

15mm x 7mm x 6mm

Write a Review
$16.80
73 in stock

Shipped in 24 Hours from Mumbai Warehouse

Adding to cart… The item has been added

About this product

The 7Semi BME690 Sensor Nano Breakout Qwiic integrates Bosch Sensortec’s latest environmental sensing technology into a compact and developer-friendly module. Designed for precision and reliability, it enables simultaneous measurement of temperature, relative humidity, barometric pressure, and gas (VOC/VSC detection) in a single device.

With a low-power architecture, digital I²C interface, and seamless Qwiic compatibility, this breakout simplifies integration into modern embedded systems. It delivers advanced outputs such as IAQ index and gas-based environmental insights, making it ideal for smart sensing applications.

Key Features

  • Operating Modes: Forced Mode, Sleep Mode, and Parallel Mode options are available.

  • High-Accuracy Measurements: Uses Bosch-calibrated sensor technology for reliable measurements.

  • Ultra-Low Power Operation: Suitable for battery-powered and low-power applications.

  • Qwiic Enabled: Provides plug-and-play I²C connectivity without soldering.

  • Fast Data Communication: Supports I²C communication speeds of up to 3.4 MHz.

  • Compact Nano Form Factor: Ideal for space-constrained designs.

  • Gas & Air Quality Sensing: Integrated gas sensing for air-quality and VOC-related applications, with Bosch BSEC software support for calculated IAQ, bVOC-equivalent, and CO₂-equivalent outputs.

What’s Included

  • 1x 7Semi BME690 Digital Sensor Nano Breakout Qwiic

Note-: qwiic cable not provided

Resources

BME690 Datasheet

DXF files

STEP Files

Arduino library
