The 7Semi DRV8210 Single Channel Motor Driver Nano Breakout is a compact and efficient dual motor driver module designed for controlling two DC motors or a single bipolar stepper motor with precision and ease. Built in an ultra-small form factor, this board is ideal for space-constrained embedded systems, robotics, and portable electronics.
This nano breakout features a dual H-bridge configuration, allowing independent bidirectional control of two motors using simple input signals. With integrated driver circuitry, it eliminates the need for complex external components, making it perfect for rapid prototyping and compact product designs.
Its low-power operation, high efficiency, and straightforward interface make it suitable for use with popular microcontrollers such as Arduino, STM32, ESP32, and Raspberry Pi. Whether you're building robots, automation systems, or smart devices, this motor driver offers reliable performance in a minimal footprint.
FEATURES:
• H-Bridge Architecture – Enables forward and reverse motor control
• Compact Nano Design – Ideal for space-constrained applications
• Simple Control Interface – Easy integration with microcontrollers
• Efficient Power Handling – Optimized for low power loss
• Fast Switching Response – Smooth motor operation
• Minimal External Components Required – Simplifies circuit design
• Stable and Reliable Operation – Suitable for embedded systems
Resources
- Product Category:
- Motor driver
- Supply voltage:
- 1.65V to 11V
- Operational temprature:
- -40C to 80C
- Current rating:
- 1A
- Number of channels:
- Single channel
- Dimension:
- L=8mm W= 4mm H= 6mm
- _3d_glb:
- https://7semi.com/content/3d-files/10499.glb
- Peak Current Rating:
- 1.7A
