7Semi ESP32-DEVKIT-UE-N16 Wifi BLE Development Board, 16MB Flash

7Semi
SKU
DC-10131

Provides a programmable Wi-Fi and Bluetooth microcontroller platform for embedded IoT applications.

top view

Select a photo to enlarge it.

50mm x 28mm x 5mm

Write a Review
$8.35
193 in stock

Shipped in 24 Hours from Mumbai Warehouse

Adding to cart… The item has been added

About this product

The ESP32-DEVKIT-UE-N16 Development Board based on ESP32-WROOM-32UE-N16 is a high-performance Wi-Fi and Bluetooth microcontroller platform built around Espressif’s ESP32 dual-core processor. This variant integrates 16MB of Flash memory, providing extended storage capacity for large firmware, OTA updates, web servers, data logging, and advanced IoT applications.

The ESP32-WROOM-32UE module features an external antenna connector for flexible antenna placement and reliable wireless connectivity in IoT and embedded applications. With integrated 2.4 GHz Wi-Fi and Bluetooth Classic + BLE, along with a rich set of peripheral interfaces, this board is ideal for IoT gateways, automation systems, robotics, smart home controllers, and embedded wireless applications.

Key Features

  • Dual-core Xtensa LX6 processor up to 240 MHz

  • 16MB Flash memory

  • Integrated 2.4 GHz Wi-Fi (802.11 b/g/n)

  • Bluetooth v4.2 BR/EDR and BLE

  • Provides U.FL Antenna Connector for an external antenna, allowing flexible antenna placement and improved wireless connectivity.

  • USB interface for programming and power

  • Rich peripheral interfaces: SPI, I2C, I2S, UART, CAN, ADC, DAC, PWM

  • 3.3V logic operation

  • Boot and reset buttons onboard

  • Improved RF performance (32E revision)

  • Compatible with ESP-IDF, Arduino IDE, and MicroPython

Includes:

  • 1 × ESP32-WROOM-32UE Development Board
  • 2.54mm pitch Header pin

Note: External antenna is not included with the product and must be purchased separately.

Resources

Datasheet

DXF Files

Step file
