The 7Semi USB to UART Isolated Converter Module is a high-reliability serial communication interface designed for safe and stable UART connectivity between computers and embedded systems.
Designed for developers, engineers, industrial automation systems, and embedded applications, the module supports baud rates up to 3 Mbps and offers selectable 3.3V / 5V UART compatibility. The integrated galvanic isolation rated up to 3000V RMS ensures robust communication in electrically noisy or high-voltage environments.
With a modern USB Type-C connector and FTDI driver compatibility across major operating systems, the module provides true plug-and-play functionality for programming, debugging, sensor interfacing, industrial communication, and isolated serial development applications.
Key Features
• Built using FTDI FT234X USB-to-UART controller for reliable serial communication
• Supports UART baud rates from 183 baud up to 3 Mbps
• USB Type-C interface for modern connectivity and easy integration
• Selectable 3.3V and 5V UART logic compatibility
• Helps eliminate ground loops and electrical noise issues
• Plug-and-play support using FTDI VCP and D2XX drivers
• Compact PCB design suitable for embedded and portable systems
• Ideal for debugging, programming, industrial communication, and sensor interfacing
Resources
FT234XD USB TO BASIC UART Datasheet
- USB Interface:
- USB 2.0 Full-Speed (12 Mbps)
- Connector Type:
- USB Type-C
- Baud Rate Range:
- 183 baud – 3 Mbps
- Signal Voltage:
- 3.3V / 5V compatible
- Operating Temperature:
- –40 °C to +85 °C
