The 7Semi CP2105 USB-UART Converter Module is a professional USB-to-serial interface board built around the Silicon Labs CP2105 IC. It provides two independent UART channels over a single USB connection, allowing a computer to communicate with two serial devices at the same time. This makes the module useful for debugging, firmware flashing, console access, and dual-device communication in embedded and industrial systems. Compared to standard single-channel USB-UART converters, the CP2105 offers two configurable serial ports, enabling simultaneous communication with different subsystems such as modems, development boards, or embedded controllers. The module connects directly through a USB Type-A interface and supports major operating systems including Windows, Linux, and macOS with stable driver support, making it easy to integrate into development and industrial environments.
Features:
• Dual UART Channels: Two independent serial interfaces available through a single USB connection.
• USB Type-A Interface: Direct connection to a computer without additional adapters.
• Reliable USB-to-Serial Communication: Suitable for debugging, firmware flashing, console access, and data monitoring.
• Wide OS Compatibility: Supports Windows, Linux, and macOS with Silicon Labs driver support.
• Simultaneous Device Communication: Can communicate with two embedded systems or serial devices at the same time.
• Compact Development Module: Small and reliable design suitable for development labs and industrial setups.
- CHIP USED:
- CP2105
- PITCH IN MM:
- 2.54MM STANDARD
- USB TYPE:
- TYPE A
- OPERATIONAL TEMPRATURE:
- -40 TO 70
- VOLTAGE SUPPORT:
- 3.3V TO 5V
- BAUD RATE:
- UPTO 2MBAUD
- DIMENSION IN mm:
- 44 x 16 x 5.3
