7Semi INA240A3 4~80V Bidirectional Current Sense Amplifier Breakout 100V/V Gain

7Semi
SKU
ES-12188

Measures bidirectional current with PWM rejection for motor and power-system monitoring.

INA240 Bidirectional Current Sense Amplifier Breakout, 4~80V input range with 100V/V gain, precision module for accurate current measurement in power and electronics systems.

Select a photo to enlarge it.

36mm x 18mm x 13.99mm

Write a Review
$7.80
Only 3 left

Shipped in 24 Hours from Mumbai Warehouse

Adding to cart… The item has been added

About this product

Overview

The 7Semi INA240A3 Current Sensor Breakout provides accurate bidirectional current measurement up to 5.3 A. It features a 100 V/V gain, a wide bus-voltage range from −4 V to +80 V, and enhanced PWM rejection for reliable readings in noisy environments. It is ideal for motor control, battery monitoring, and power-management applications.

Key Features

  • Bidirectional current measurement up to 5.3A.
  • Wide bus-voltage range from −4V to +80V.
  • High current-sense gain of 100V/V.
  • Enhanced PWM noise rejection.
  • Analog voltage output.
  • Compatible with 3.3V and 5V systems.
  • Onboard 10mΩ 3W sense resistor
