7Semi INA240A4 4~80V Bidirectional Current Sense Amplifier Breakout, 200V/V Gain

7Semi
SKU
ES-12187

Measures bidirectional current with PWM rejection for motor and power-system monitoring.

INA240 Bidirectional Current Sense Amplifier Breakout, 4~80V input range with 200V/V gain, high-accuracy module for precision current measurement in power systems.

Select a photo to enlarge it.

36mm x 18mm x 13.99mm

Write a Review
$7.80
58 in stock

Shipped in 24 Hours from Mumbai Warehouse

Adding to cart… The item has been added

About this product

The 7Semi INA240A4 Current Sensor Breakout provides accurate bidirectional current measurement up to 2.5 A. It features a 200 V/V gain, a wide bus-voltage range from −4 V to +80 V, and enhanced PWM rejection for reliable readings in noisy environments. It is ideal for motor control, battery monitoring, and power-management applications.

Key Features

  • Bidirectional current measurement up to 2.5A.
  • Wide bus-voltage range from −4V to +80V.
  • High current-sense gain of 200V/V.
  • Gain error up to ±0.20%.
  • Enhanced PWM noise rejection.
  • Analog voltage output.
  • Compatible with 3.3 V and 5 V systems.
  • Onboard 10 mΩ sense resistor.
