The 7Semi Vikram-3025 is a heavy-duty motor driver designed to control a single DC motor with very high current support. It works with input voltages from 6V to 30V and can handle up to 25A continuous current, making it suitable for powerful motors and demanding applications. . A built-in 5V output is available to power other circuits, reducing the need for extra components. With strong build quality and safety features, this driver is ideal for robotics, automation systems, and high-power motor control projects.
Features:
• Single Motor Control: Designed to drive one high-power DC motor.
• Very High Current Support: Handles up to 25A continuous current.
• Wide Voltage Range: Works from 6V to 30V DC input.
• Direction & Speed Control: Supports forward, reverse, and PWM speed control.
• Onboard Test Buttons: Easy testing without external controller.
• LED Indicators: Shows motor output status clearly.
• Wide Logic Compatibility: Works with different control signal levels.
• Built-in Protection: Includes over-current, over-temperature, and under-voltage protection.
On-board Motor Quick Test Buttons Demo
- Operational Voltage:
- 6V to 30V DC
- Category of product:
- Industrial Motor driver
- Peak Output current:
- 25A
- Topology:
- Full H-bridge
- _3d_glb:
- https://7semi.com/content/3d-files/10117.glb
- Operating Temperature:
- -40°C to +85°C
- Dimensions in mm:
- 85mm x 60mm x 22.84mm
