7Semi BMI270 Nano - 6-Axis IMU Sensor Board Qwiic

SKU
ES-12250

Combines three-axis acceleration and rotation sensing for motion, tilt and activity detection.

Angled view of 7SEMI BMI270 Nano board highlighting the BMI270 chip and compact size

Select a photo to enlarge it.

14mm x 7mm

Write a Review
$6.20
64 in stock

Shipped in 24 Hours from Mumbai Warehouse

Adding to cart… The item has been added

About this product

The 7Semi BMI270 Nano is a compact, low-power 6-axis IMU featuring a 3-axis accelerometer and 3-axis gyroscope. It provides accurate motion, tilt, gesture, and activity detection with onboard processing and a 2 KB FIFO. The Qwiic-compatible connector enables easy integration with Arduino, ESP32, STM32, Raspberry Pi, and other development platforms.

Key Features

  • 16-bit 3-axis accelerometer and gyroscope

  • Accelerometer ranges: ±2 g, ±4 g, ±8 g and ±16 g

  • Gyroscope ranges: ±125 dps to ±2000 dps

  • Any-motion, no-motion and significant-motion detection

  • Step counting and wrist-gesture recognition

  • Integrated 2 KB FIFO with timestamps

  • I²C and SPI communication interfaces

  • Auxiliary I²C interface for external sensors

  • Low current consumption: 685 µA typical

  • Qwiic/STEMMA QT-compatible connector

What’s Included

  • 1x BMI270 Nano - 6-Axis IMU Sensor Board

Resources

BMI270 Datasheet

DFX File

STEP File

Arduino library
